ELECTRICALLY CONDUCTIVE UNDERLAYS

Get Accurate Leak Detection with Conductive Underlays

Keep you & your project safe with electronic leak detection, enabled by our electrically conductive membrane underlays across Australia.

Prolong the life of your roof

Save time and money on identifying membrane failures

Avoid unnecessary repairs

Protect the internal contents

Allows ELD testing over non-conductive substrates

Minimise maintenance costs

Proactive quality assurance

Proven Membranes Controlit underlays allow you to perform electronic leak detection when laid over non-conductive substrates, meeting ASTM 7877-14 guidelines.

Controlit underlays help you cut costs on traditional waterproof testing methods and save precious project time by enabling electronic leak detection.

Ensure easy quality assurance in building maintenance, warranty programs and the construction process by preparing for electronic leak detection with our underlays.

Conductive underlays are suitable for

Apartments and Office Buildings

Schools

Factories and Warehouses

Shopping Centers and Hotels

Swimming Pools

Cultural and Data Centers

Our range of Controlit Conductive Underlays

There are four different Controlit underlay options, each with unique features and uses. If you’re unsure which is the best for your project, don’t hesitate to give our friendly team a call to chat.

Controlit GS

165 g/m2, conductive woven glass underlay for bitumen waterproofing membranes

Completely fireproof - fire behaviour class A2-s1, d0

Plasma treated to have perfect adhesion

With torchable membranes

Electrical resistance <1000Ohms/sq

Tensile strength warp 2500 N/5cm, we 2000 N/5cm

Compatible with any ELD method

Can be used as a separation layer

Controlit GS Single Ply

165 g/m2, conductive woven glass underlay for synthetic waterproofing membranes

Fire behaviour class A2-s1, d0

Electrical resistance <1000Ohms/sq

Tensile strength warp 2500 N/5cm, we 2000 N/5cm

Compatible with any ELD method

Can be used as a separation layer

Controlit PK

300 g/m2, conductive PES geotextile underlay for synthetic waterproofing membranes

Can replace existing geotextile

Electrical resistance <10’000Ohms/sq

Compatible with any ELD method

Can be used as a separation layer

Controlit GSP

165 g/m2, conductive woven glass underlay for synthetic swimming pool waterproofing membranes

Anti-fungal and anti-bacterial additives

Electrical resistance <1000Ohms/sq

Tensile strength warp 2500 N/5cm, we 2000 N/5cm

Compatible with any ELD method

How it works

Get in touch

If you need help with anything waterproofing-related, our experienced team would love to help. Give us a call today to pick our brains, weigh up your options or get a quote today.
